c. Remove the module (3) from the display enclosure. (The module is attached to the display
enclosure with double-sided tape.)
13. If you need to remove the display hinges, remove the six broadhead Phillips PM 2.0×2.0 screws (1), and
then lift the hinges from the display enclosure (2).
96 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts ENWW
