Table 5-3 Memory module descriptions and part numbers
Description Spare part number
16 GB, DDR4-4800 M97596-005
8 GB, DDR4-4800 M97595-005
Memory module cover N13393-001
Before removing the memory, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 33).
2. Remove the bottom cover (see Bottom cover on page 33).
3. Remove the battery (see Battery on page 34).
If you are replacing a memory module, remove the existing memory module:
1. Use a nonmarking, nonconductive tool to release the edges of the bottom cover from the system board
(1), and then remove the memory module cover (2).
2. Spread the two retention clips outward (1) until the memory module tilts up at a 45° angle, and then
remove the module (2). Use the same procedure to remove all memory modules.
IMPORTANT: To prevent damage to the memory module, hold the memory module by the edges only.
Do not touch the components on the memory module.
36 Chapter 5Removal and replacement procedures for authorized service provider parts
