# Specify the security policy server.
[SwitchA-radius-rs1] security-policy-server 192.168.0.113
[SwitchA-radius-rs1] quit
# Enable RADIUS session control.
[SwitchA] radius session-control enable
2. Configure an authentication domain:
# Create an ISP domain named dm1 and enter its view.
[SwitchA] domain dm1
# Configure AAA methods for the ISP domain.
[SwitchA-isp-dm1] authentication portal radius-scheme rs1
[SwitchA-isp-dm1] authorization portal radius-scheme rs1
[SwitchA-isp-dm1] accounting portal radius-scheme rs1
[SwitchA-isp-dm1] quit
# Configure domain dm1 as the default ISP domain. If a user enters the username without the ISP
domain name at login, the authentication and accounting methods of the default domain are used
for the user.
[SwitchA] domain default enable dm1
3. Configure ACL 3000 as the isolation ACL and ACL 3001 as the security ACL:
[SwitchA] acl number 3000
[SwitchA-acl-adv-3000] rule permit ip destination 192.168.0.0 0.0.0.255
[SwitchA-acl-adv-3000] rule deny ip
[SwitchA-acl-adv-3000] quit
[SwitchA] acl number 3001
[SwitchA-acl-adv-3001] rule permit ip
[SwitchA-acl-adv-3001] quit
NOTE:
Make sure you specify ACL 3000 as the isolation ACL and ACL 3001 as the security ACL on the
security policy server.
4. Configure portal authentication:
# Configure a portal authentication server.
[SwitchA] portal server newpt
[SwitchA-portal-server-newpt] ip 192.168.0.111 key simple portal
[SwitchA-portal-server-newpt] port 50100
[SwitchA-portal-server-newpt] quit
# Configure a portal Web server.
[SwitchA] portal web-server newpt
[SwitchA-portal-websvr-newpt] url http://192.168.0.111:8080/portal
[SwitchA-portal-websvr-newpt] quit
# Enable cross-subnet portal authentication on VLAN-interface 4.
[SwitchA] interface vlan-interface 4
[SwitchA–Vlan-interface4] portal enable method layer3
# Reference the portal Web server newpt on VLAN-interface 4.
[SwitchA–Vlan-interface4] portal apply web-server newpt
