Table 3 International Single-Phase Power Specifications
Modular PDU 1-phaseiPDU 1-phaseR5000 1-phase UPS
32 A32 A4500 WOutput Load
200 – 240 V200 – 240 V220 – 240 VInput Voltage
IEC309 332P6IEC309 332P6IEC309 332P6Input Connector
(32 A)(32 A)(32 A)
N/AN/A220 – 240 VOutput Voltage
4x C196 x C191 x IEC309 332R6Output Connectors
(28 x C13)(20 x C13)4 x C19
4 x C13
UPS outputs are connected to the compatible PDU inputs.Notes
Table 4 International Three-Phase Power Specifications
Modular PDU 3-phaseiPDU 3-phaseR12000 3-phase UPS
16 A/phase16 A/phase12 kWOutput Load
380-415V 3P Wye380-415V 3P Wye380-415V 3P WyeInput Voltage
IEC309 516P6IEC309 516P6IEC309 532P6Input Connector
(32 A)(32 A)(32 A)
N/AN/A400V 3P WyeOutput Voltage
6 x C19 (20 A)6 x C192 x IEC309 309 516C6Output Connectors
(42 x C13)(20 x C13)
UPS outputs are connected to the compatible PDU inputs.Notes
46 System Installation Specifications for NS2300 Systems
