Maximum Power
Consumption (Watts)
Typical Power
Consumption (Watts)
AC Power Lines per
Enclosure
1
Enclosure Type
1901402Gen9 Storage CLIM
2001302G6 IP or Telco CLIM
2031172
Gen8 Networking CLIM 5
copper ports (IP or Telco)
2101232
Gen8 Networking CLIM 3
copper/2 optical ports (IP or
Telco)
180130
Gen9 Networking CLIM, 5
copper ports (IP or Telco)
185135
Gen9 Networking CLIM, 3
copper/2 optical ports (IP or
Telco)
125752
D2700 SAS disk enclosure
(no disks)
125752
D3700 SAS disk enclosure,
empty
95-SAS disk drive 10k rpm
74-SAS disk drive 15k rpm
66-200GB SAS 2.5” SSD, Gen1
66-200GB SAS 2.5” SSD, Gen2
66-400GB SAS 2.5” SSD
1151051Rack-mounted system
console (NSCR212)
28281Rack-mounted keyboard and
monitor
20201Maintenance switch (Ethernet)
2
1
One of the plugs for an enclosure must be connected to one of the left-side extension bars and the other one connected
to one of the right-side extension bars. PDUs must be supplied from separate branch circuits.
2
Maintenance switch has only one plug. If a UPS is installed in the rack, the maintenance switch plug must be connected
to the extension bars on the right side of the rack.
48 System Installation Specifications for NS2300 Systems
