This table lists the PDUs, supported configurations, and links to examples that use a 42U rack.
Examples of ConfigurationsSupported PDU ConfigurationsPDU Types
• 4 single-phase iPDUs without UPS (page 26)
Four PDU cores without UPSiPDU
• 4 iPDUs with single-phase UPS (page 27)
• 4 iPDUs with three-phase UPS (page 28)
Four PDU cores with UPS
• 2 iPDUs without UPS (page 29)
Two PDU cores without UPS
• 2 iPDUs with single-phase UPS (page 30)
Two PDU cores with UPS
• 2 iPDUs with three-phase UPS (page 31)
• 4 mPDUs without UPS (page 32)
Four PDU cores without UPSModular
• 4 mPDUs with single-phase UPS (page 33)
Four PDU cores with UPS
• 4 mPDUs with three-phase UPS (page 34)
• 2 mPDUs without UPS (page 35)
Two PDU cores without UPS
• 2 mPDUs with single-phase UPS (page 36)
Two PDU cores with UPS
• 2 mPDUs with three-phase UPS (page 37)
Power Distribution Unit (PDU) Types for a Rack 25
