NS7 Enclosure Power Loads
The total power and current load for a rack depends on the number and type of enclosures
installed in it. Therefore, the total load is the sum of the loads for all installed enclosures.
In normal operation, the AC power is split equally between the power feeds on the two sides (left
and right) of the rack. However, if AC power fails on one side of the rack, the power feed(s) on
the remaining side must carry the power for all enclosures in that rack.
NOTE: For NS7 CG X2 system specifications, see “System Installation Specifications for NS7
CG Systems” (page 70).
Power and current specifications for each type of enclosure are:
Maximum Power
Consumption (VA)
2
Typical Power
Consumption (VA)
1
AC Power Lines per
Enclosure
Enclosure Type
Products used by NS7 X1
AC systems
230230-
BL460c Gen8 CPU
(64 GB RAM)
260260-
BL460c Gen8 CPU
(128 GB RAM)
290290-
BL460c Gen8 CPU
(192 GB RAM)
Products used by NS7 X2
AC systems
300300
-
BL460c Gen9 CPU
(64 GB RAM)
315315
-
BL460c Gen9 CPU
(128 GB RAM)
330330
-
BL460c Gen9 CPU
(192 GB RAM)
Common products used by
NS7 X1 and NS7 X2 AC
systems:
12508106c7000 enclosure
2342072
FDR IB ADI switch (for
NSADI)
2342072FDR IB switches expansion
2342072
FDR IB cluster switch (for
NonStop X Cluster Solution)
1601302Gen8 Storage CLIM
1561262
Gen8 Networking CLIM,
4C/1C (IP or Telco)
1581282
Gen8 Networking CLIM,
3C/2F (IP or Telco)
1901402Gen9 Storage CLIM
