1 HPE Integrity NonStop X NS7 Systems
The HPE Integrity NonStop X NS7 system family introduces Intel® Xeon® x86 technology to
NonStop by using a new high bandwidth, low latency InfiniBand system interconnect that is
fully-integrated with the fault-tolerant HPE NonStop Operating system.
The L15.08 RVU introduced the NS7 X1.
The L16.05 RVU introduces the NS7 X2 and the NS7 CG X2.
Table 1 Characteristics of the NS7 X1
Intel® Xeon® x86 processorsProcessor/Processor model
L15.02 and later RVUsSupported RVU for the system
The core license file is required. See Core Licensing (page 9)2-, 4-, and 6-core software
licensing options
See the CLuster I/O Module (CLIM) Software Compatibility Guide for supported
version
CLIM DVD (Minimum DVD
version required for RVU)
NOTE: This file is preinstalled on new systems
36U or 42URack
2 to 16 processors configured in pairsProcessors
64GB, 128GB, and 192GB memory configurationsMemory
See Planning Kernel Managed Swap (KMS) Space (page 59).Kernel Managed Swap Facility
56 CLuster I/O Modules (CLIMs) — Storage, IP, or TelcoMaximum CLIMs in a 16 CPU
NonStop X system
Minimum CLIMs for
fault-tolerance
• 2 Storage CLIMs
• 2 Networking CLIMs (IP or Telco)
A Storage CLIM pair supports a maximum of 4 SAS disk enclosuresMaximum SAS disk enclosures
100 per Storage CLIM pair.Maximum SAS disk drives
HPE LTO6 Tape Data Cartridge, HPE NonStop BackBox VTC, and HPE NonStop
BackBox VTR
Tape support through Storage
CLIMs
0 to 4 (2 pairs)Minimum/maximum IO
Expansion IB Switches
HPE XP 7 Storage Array and HPE XP P9500 Storage ArrayESS support through Storage
CLIMs
This file is required; see Core Licensing (page 9)Core licensing file
Redundant configuration onlyMaintenance LAN
2Minimum NonStop System
Consoles for fault-tolerance
Supported. For more information, see the NonStop X Cluster Solution Manual
Connection to NonStop X
Cluster Solution
“NonStop X NS7 Standard and Optional Hardware” (page 10) describes the NS7 system hardware.
Because NS7 systems offer flexibility in how hardware is distributed in the rack, configurations
can vary. Figure 1 shows two example configurations for AC power NS7 systems.
7
