Maximum Power
Consumption (VA)
2
Typical Power
Consumption (VA)
1
Power Lines per EnclosureNS7 CG X2 Enclosure Type
1451351Deskside system console
26231Deskside system Console
monitor
1
Typical = measured at 22C ambient temp
2
Maximum = measured at 35C ambient temp
Dimensions and Weights of NS7 CG Systems
Seismic Rack Specifications for NS7 CG Systems
All information for connecting, grounding and installing an NS7 CG system is available to your
authorized service provider.
36U Seismic Rack Specification for NS7 CG Systems
71.4 in H x 26.7 in W x 39.4 in D
181.3 cm H x 67.8 cm W x 100 cm D
Cable entry is from the top
Maximum payload is 1200 lbs (544 kg)
Rack weight is 451 lbs ( 204 kg)
Packaging and pallet weight is 200 lbs (91 kg)
Service Clearance and Floor Space Requirements
RecommendedMinimum
Measurement cmincmin
13051.291.436Front (appearance side) clearance
13051.291.436Rear (service side) clearance
< 2.5< 1.0----Space between racks
68.627----Rack pitch
Unpacking area: When moving the rack off the shipping pallet, you need approximately 9 feet
(2.74 meters) on one side of the rack to allow you to slide the pallet out from under the rack after
the rack has been raised on the casters.
Unit Sizes for NS7 CG Systems
Height (U)Enclosure Type
2Fuse Panel
2Breaker panel
1System alarm panel
11 (includes seismic brace)c7000 CG enclosure
2CLIMs CG
1CLIM CG Patch Panel
Dimensions and Weights of NS7 CG Systems 73
