NS7 Enclosure Power Loads
The total power and current load for a rack depends on the number and type of enclosures
installed in it. Therefore, the total load is the sum of the loads for all installed enclosures.
In normal operation, the AC power is split equally between the power feeds on the two sides (left
and right) of the rack. However, if AC power fails on one side of the rack, the power feed(s) on
the remaining side must carry the power for all enclosures in that rack.
NOTE: For NS7 CG X2 power distribution, see “DC Power Distribution for NS7 CG Systems”
(page 70).
Power and current specifications for each type of enclosure are:
Maximum Power
Consumption (VA)
2
Typical Power
Consumption (VA)
1
Power Lines per EnclosureNS7 CG X2 Enclosure Type
22508106c7000 CG enclosure
300300
-
BL460c Gen9 CG CPU
(64 GB RAM)
315315
-
BL460c Gen9 CG CPU
(128 GB RAM)
330330
-
BL460c Gen9 CG CPU
(192 GB RAM)
2701402Gen9 Storage CLIM CG
265135
2
Gen9 Networking CLIM CG ,
4C/1C (IP or Telco)
2651352
Gen9 Networking CLIM CG,
3C/2F (IP or Telco)
234207
2
FDR IB ADI switch (must be
installed in separate rack)
7732GB Memory kit
100752
CG SAS disk enclosure,
empty
66-400GB SSD, 12G SAS, SFF,
SC
74-300GB, 15k rpm HDD, 12G
SAS, SFF, SC
40351CG Maintenance switch
(Ethernet)
4202102Breaker panel
140702Fuse panel
1052Alarm panel
1291291Rack-mount system console
(must be installed in separate
rack)
36361Console keyboard and
monitor
72 System Installation Specifications for NS7 CG Systems
