Branch Circuit Protection Per RailNS7 CG Component
3 x 80Ac7000 CG enclosure
15ACLIM CG
30ACG SAS disk enclosure
2ACG Maintenance switch
2AAlarm panel
100A (input rated)Fuse panel
300A (input rated)Breaker panel
DC Power Distribution for NS7 CG Systems 71
