6 System Installation Specifications for NS7 CG Systems
This chapter provides specifications necessary for planning the installation of NS7 CG systems.
DC Power Distribution for NS7 CG Systems
Examples of NS7 CG Power Distributions
Branch Circuit Protection Per RailNS7 CG Component
3 x 80Ac7000 CG enclosure
15ACLIM CG
30ACG SAS disk enclosure
2ACG Maintenance switch
2AAlarm panel
100A (input rated)Fuse panel
70 System Installation Specifications for NS7 CG Systems
