Total (BTU/hour)Unit Heat (BTU/hour,
Maximum Heat
Dissipation)
Unit Heat
(BTU/hour, Typical
Heat Dissipation)
Number InstalledEnclosure Type
631461Gen9 10GbE
Networking CLIM
4F/1C
614426SAS disk enclosure,
empty
2313SAS HDD, 2.5 inches,
15k rpm
2414SAS, SSD, 2.5in, SC,
15k rpm
5131Maintenance switch
(Ethernet)
1
569569Rack-mounted
system console
129129Console keyboard
and display
1
Maintenance switch has only one plug.
Operating Temperature, Humidity, and Altitude Specifications for NS7 Systems
Maximum Rate of Change
per Hour
Recommended Range
1
Operating Range
1
Specification
41° to 95° F (5° to 35° C)Temperature (rack-mounted
system console, and
maintenance switch)
9° F (5° C) Repetitive68° to 72° F
36° F (20° C) Nonrepetitive(20° to 25° C)
-50° to 95° F (10° to 35° C)Temperature (c7000,
CLIMs, and SAS disk
enclosures)
1.8° F (1° C) Repetitive
5.4° F (3° C) Nonrepetitive
6%, noncondensing40% to 50%,
noncondensing
15% to 80%,
noncondensing
Humidity (all except c7000
enclosure)
6%, noncondensing40% to 55%,
noncondensing
20% to 80%,
noncondensing
Humidity (c7000 enclosure)
--0 to 10,000 feet (0 to 3,048
meters)
Altitude
2
1
Operating and recommended ranges see the ambient air temperature and humidity measured 19.7 in. (50 cm) from
the front of the air intake cooling vents.
2
For each 1000 feet (305 m) increase in altitude above 10,000 feet (up to a maximum of 15,000 feet), subtract 1.5× F
(0.83× C) from the upper limit of the operating and recommended temperature ranges.
56 NS7 System Installation Specifications
