HP Intelligent Power Distribution Unit User Manual

Installing the HP Intelligent Power Distribution Unit 30
Extension Bar Total rating of
Extension Bar
Outlet style Individual outlet
rating
Outlet monitor and
control
AF528A 16 A IEC-320 C13 10 A No
AF529A
Intelligent
16 A IEC-320 C13 10 A Yes
Server spatial ordering can be achieved by connecting the Intelligent Extension Bars numbering from the
bottom of the rack. Insight Control power management v6.2 will draw the servers in order based on this
best practice so that only minimal arrangement is needed to place the servers in the actual U position in
the rack.
