Virus Throttling (Connection-Rate Filtering)
Configuring Connection-Rate Filtering
Example of a Basic Connection-Rate Filtering Configuration
Figure 3-2. Sample Network
Basic Configuration. Suppose that in the sample network, the administra-
tor wanted to enable connection-rate filtering and configure the following
response to high connection-rate traffic on the switch:
■ Ports B1 - B3: Throttle traffic from the transmitting host(s).
■ Port B4: Respond with Notify-Only to identify the transmitting
host(s).
■ Ports B9, D1, and D2: Block traffic from the transmitting host(s).
Figure 3-3 illustrates the configuration steps and resulting startup-config file.
HP Switch
Server
Company
Intranet
VLAN 1
15.45.100.1
VLAN 10
15.45.200.1
Server
VLAN 15
15.45.300.1
Switch
Server
Server
Switch
Switch
A
B
C
D
E
H
F
G
B10
B11
B12
B19
B13
D21
D22
To Next Page
