HP jetdirect 175x User Manual

ENWW HP Jetdirect 802.11b Wireless Print Servers 256
Channels
The band of radio signals used for IEEE 802.11b wireless
networking are segmented into specific frequencies, or "channels".
For IEEE 802.11b wireless networks, 14 channels are available. But
each country/region specifies the channels that are authorized for
use. For example, in North America, only channels 1 through 11 are
allowed. In Japan, channels 1 through 14 can be used. In Europe,
except for France, channels 1 through 13 are allowed. Because of
frequent changes to existing standards, you should check with your
local regulatory agencies for authorized channel use. Note that, in
most countries/regions channels 10 and 11 may be used without
restriction.
Channel selection on the HP Jetdirect wireless print server depends
on the Communication Mode (or topology) of the network.
● In Ad Hoc (Peer-to-Peer) Mode, the HP Jetdirect wireless
print server will initially scan all channels for the network
specified by the Network Name (SSID), for example hpsetup.
If the specified Ad Hoc network is detected, the print server will
configure and use the channel that the network uses.
If the specified Ad Hoc network is not detected, the print server
will actively transmit and advertise itself using a selected
channel. By factory default, channel 10 (2457 MHz) will be used.
However, channel 11 (2462 MHz) is also available.
If the print server fails to associate with a network, it will
repeatedly scan on all channels and then actively transmit on
the selected channel (channels 10 or 11) until it associates with
the specified network.
● In Infrastructure Mode, the channel will be determined by
the Access Point to which the print server connects. The HP
Jetdirect print server, as with other clients, will adapt its
channel to the one required.
The channels available on your HP Jetdirect wireless print server
depend on your print server model. For supported channels, see the
documentation included with your HP Jetdirect wireless print
server.

HP jetdirect 175x Specifications

General

Network ready	Yes
Power supply type	AC/DC
Cabling technology	10/100Base-T(X)
Networking features	Fast Ethernet
Compatible operating systems	Windows 98 Windows NT 4.0 Windows Me Windows 2000 Windows Server 2003 Windows XP (32/64-bit) Windows Vista (32/64-bit) Windows 2003 (64-bit) Mac OS 8.6+
Product color	White
Firmware upgradeable	No
Number of simultaneous printers	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	15 - 95 %
Safety	IEC
Certification	FCC, DoC
AC input voltage	100-127 V
AC input frequency	60 Hz
Power consumption (typical)	2.8 W
Supported network protocols	TCP/IP, IPX/SPX, AppleTalk, IP Direct, LPD, Telnet, SLP, IGMP, BOOTP/DHCP, WINS, SNMP, HTTP, Auto-IP, Bonjour
Flash memory	2 MB
Minimum storage drive space	40 MB
Minimum system requirements	CD-ROM
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Network connection type	Ethernet LAN
Copper ethernet cabling technology	100BASE-T, 100BASE-TX, 10BASE-T
USB connector type	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	0
Cables included	USB

Weight and Dimensions

Depth	127 mm
Width	101.6 mm
Height	38.1 mm
Weight	118 g
