HP jetdirect 175x User Manual

ENWW TCP/IP Configuration 43
● RARP. A network-based server can use RARP (Reverse Address
Resolution Protocol) to answer the print server's RARP request
and supplying the print server with the IP address. The RARP
method only allows you to configure the IP address. For more
information, see “Using RARP
”.
● arp and ping commands. (For print servers configure with
Legacy default IP address 192.0.0.192 only) You can use the arp
and ping commands from your system. For more information,
see “Using the arp and ping Commands
”.
● Telnet. You can set configuration parameters using Telnet. In
order to set configuration parameters, set up a Telnet
connection from your system to the HP Jetdirect print server
using the default IP address. Once configured, the print server
saves the configuration when powered off/on. For more
information, see “Using Telnet
”.
● Embedded Web server. You can browse to the embedded Web
server on the HP Jetdirect print server and setting the
configuration parameters. For more information, see Chapter 4
.
● Printer Control Panel. (Internal Jetdirect print servers only)
You can manually enter the configuration data using the printer
control panel keys. The control panel method allows you to
configure only a limited subset of configuration parameters
(IP address, subnet mask, default gateway address, and
idle timeout). Therefore, control panel configuration is
recommended only during troubleshooting or for simple
installations. If control panel configuration is used, the print
server saves the configuration when powered off/on. For more
information, see “Using the Printer Control Panel
”.

HP jetdirect 175x Specifications

General

Network ready	Yes
Power supply type	AC/DC
Cabling technology	10/100Base-T(X)
Networking features	Fast Ethernet
Compatible operating systems	Windows 98 Windows NT 4.0 Windows Me Windows 2000 Windows Server 2003 Windows XP (32/64-bit) Windows Vista (32/64-bit) Windows 2003 (64-bit) Mac OS 8.6+
Product color	White
Firmware upgradeable	No
Number of simultaneous printers	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	15 - 95 %
Safety	IEC
Certification	FCC, DoC
AC input voltage	100-127 V
AC input frequency	60 Hz
Power consumption (typical)	2.8 W
Supported network protocols	TCP/IP, IPX/SPX, AppleTalk, IP Direct, LPD, Telnet, SLP, IGMP, BOOTP/DHCP, WINS, SNMP, HTTP, Auto-IP, Bonjour
Flash memory	2 MB
Minimum storage drive space	40 MB
Minimum system requirements	CD-ROM
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Network connection type	Ethernet LAN
Copper ethernet cabling technology	100BASE-T, 100BASE-TX, 10BASE-T
USB connector type	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	0
Cables included	USB

Weight and Dimensions

Depth	127 mm
Width	101.6 mm
Height	38.1 mm
Weight	118 g
