68 Troubleshooting
speed remains under the 4,000 RPM threshold, the internal enclosure temperature may continue to rise.
Replace the power supply reporting the fault.
During a shutdown, the cooling fans do not shut off. This allows the enclosure to continue cooling.
Temperature sensors
Extreme high and low temperatures can cause significant damage if they go unnoticed. Each controller
module has six temperature sensors. Of these, if the CPU or FPGA (Field Programmable Gate Array)
temperature reaches a shutdown value, the controller module is automatically shut down. Each power
supply has one temperature sensor.
When a temperature fault is reported, it must be remedied as quickly as possible to avoid system damage.
This can be done by warming or cooling the installation location.
When a power supply sensor goes out of range, the Fault/ID LED illuminates amber and an event is
logged to the event log.
Table 22 Cooling fan sensor descriptions
Description Location Event/Fault ID LED condition
Fan 1 Power supply 1 < 4,000 RPM
Fan 2 Power supply 1 < 4,000 RPM
Fan 3 Power supply 2 < 4,000 RPM
Fan 4 Power supply 2 < 4,000 RPM
Table 23 Controller module temperature sensor descriptions
Description Normal operating
range
Warning operating
range
Critical operating
range
Shutdown values
CPU temperature 3°C–88°C0°C–3°C,
88°C–90°C
> 90°C0°C
100°C
FPGA temperature 3°C–97°C0°C–3°C,
97°C–100°C
None 0°C
105°C
Onboard temperature 1 0°C–70°CNoneNoneNone
Onboard temperature 2 0°C–70°CNoneNoneNone
Onboard temperature 3
(Capacitor temperature)
0°C–70°CNoneNoneNone
CM temperature 5°C–50°C 5°C,
50°C
0°C,
55°C
None
Table 24 Power supply temperature sensor descriptions
Description Normal operating range
Power Supply 1 temperature 10°C–80°C
Power Supply 2 temperature 10°C–80°C
