HP MSR Router Series Configuration Guide

51
Step Command Remarks
8. Configure the SOH and
higher-order path overhead
bytes.
flag { c2 path-number c2-value | s1
s1-value | s1s0 path-number
s1s0-value }
flag { j0 | j1 path-number } { sdh |
sonet } flag-value
By default:
• c2 is 0x02.
• s1 is 0x0f.
• s1s0 is 0x00 for SONET and
0x02 for SDH.
• j0 is 0x01 for SONET and a
16-byte empty character string
for SDH.
• j1 is a 64-byte empty character
string for SONET and a 16-byte
empty character string for SDH.
9. Set the signal degrade (SD) or
signal fail (SF) alarm threshold
for the interface.
threshold { sd sdvalue | sf sfvalue }
*
The default SD and SF alarm
thresholds are 6 and 3,
respectively.
10. (Optional.) Restore the default
settings for the CPOS
interface.
default N/A
11. Bring up the CPOS interface.
undo shutdown
By default, a CPOS interface is up.
If no cable is connected to a
physical interface, shut down the
interface with the shutdown
command to prevent problems.
Configuring an E1 channel
The serial interfaces created for E1 channels have the same logical features as a synchronous serial
interface. You can configure these serial interfaces in the same way you configure a standard
synchronous serial interface. For more information about configuring synchronous serial interfaces, see
"Configuring WAN interfaces."
To configure an E1 channel:
Step Command Remarks
1. Enter system view.
system-view N/A
2. Enter CPOS interface view.
controller cpos cpos-number N/A
3. Set the framing format for the
E1 channel.
e1 e1-number frame-format { crc4
| no-crc4 }
The default setting is no-CRC4.
4. Set the clock mode for the E1
channel.
e1 e1-number clock { master |
slave }
The default setting is slave.
5. (Optional.) Enable loopback
on the E1 channel.
e1 e1-number loopback { local |
payload | remote }
By default, loopback is disabled.
6. Set overhead bytes for the E1
channel.
e1 e1-number flag c2 c2-value
e1 e1-number flag j2 { sdh |
sonet } j2-string
By default, C2 is set to
hexadecimal 02, and J2 contains
cyclic empty character strings.
