Figure 3-2 SUV Cable
1
Server Blade Connector
2
2-Port USB
3
VGA (no access to iLO 2 MP)
4
9-Pin Console Serial Port (RS-232)
5
USB Label
6
USB-1
7
USB-0
Physically Connecting the Server Blade to the iLO 2 MP 45
