1-2 Product Information HP OmniBook XE2
Features and Operation
The following five illustrations point out the main external features of the computer. They are
followed by highlights of the computer’s operation. For an internal, exploded view, see page 4-2.
Figure 1-1. OmniBook Front View
1 Latch to open the OmniBook 7 Click buttons
2 Built-in microphone 8 CD player power (on selected models)
3 Blue power button 9 CD player buttons (on selected models)
4 Status lights 10 CD-ROM drive
5 Built-in speakers 11 Kensington lock slot (security connector)
6 Touch pad (pointing device) 12 Modem phone jack (on selected models)
Figure 1-2. OmniBook Side View
13
PC Card eject buttons
14
PC Card and CardBus slots (upper and
lower)
15
Floppy disk drive
