HP OmniBook XE2 Product Information 1-3
Figure 1-3. OmniBook Bottom View
16 System-off button 20 Battery latch
17 Hard disk drive latch and locking screw 21 Battery
18 Hard disk drive 22 Port replicator connector
19 RAM expansion cover
Figure 1-4. OmniBook Rear View
1 Parallel port 6 Infrared port
2 Serial port 7 USB port
3 VGA port (external monitor) 8 PS/2 port
4 Audio out (external speaker) 9 AC adapter jack
5 Microphone jack
