HP OmniBook XE2 Removal and Replacement 2-13
Figure 2-8. Removing the LCD Module
LCD module
Inverter PCA
Display case
Display bezel
Screw covers
Right LCD bracket
Left LCD bracket
Note: In some models,
the inverter PCA is at
the bottom of the LCD
module.
Hinges
