Specifications and Regulatory Information
Hardware and Software Specifications
Reference Guide 127
Simple Port
Replicator
Serial
Parallel
VGA
USB x2
TV-out
PS/2 x2
RJ-45
Audio line-in
Audio microphone-in
Audio headphone-out
DC-in (with AC adapter)
LEDs:
– SysON LED: green when system is on.
– BATT Charge LED: amber when Batt in charging, green when fully charged,
red for abnormal
Power on/off slide switch
Kensington lock
Environment Operating temperature: 5 to 35°C (41 to 95°F)
Storage temperature: -20 to 50°C (-4 to 122°F)
Operating humidity: 20 to 90% RH (5 to 35°C)
Operating shock: 60inch/sec, 2ms, half-sine
Non-operating shock: 80inch/sec, 2ms, half-sine
Operating vibration: 1G (5 to 500Hz)
Non-operating vibration: 2.16G (5 to 500Hz)
Hinge cycle life: 20K cycles
Operating altitude: up to 3,000m (10,000 ft)
Standards PC99
ACPI
