System Components
Startup and Reference Guide—Part 2 2–9
Rear Panel
Connectors and Jacks
Rear Panel: Connectors and Jacks
1
Security cable slot Attaches an optional security cable to
the notebook.
2
RJ-11 telephone jack Connects a modem cable. (A modem
cable is included with select models.)
3
RJ-45 network jack Connects an Ethernet network cable.
(An Ethernet network cable is included
with select models.)
4
USB connectors (3) Connect optional 1.1 or 2.0-compliant
USB devices.
5
S-Video jack Connects an optional S-Video device,
such as a television, VCR, camcorder,
projector, or video capture card.
6
Parallel connector (available
on select models)
Connects an optional parallel device
such as a printer.
7
External monitor connector Connects an optional VGA external
monitor or projector.
Ryan Masterfile.book Page 9 Monday, June 9, 2003 2:33 PM
