HP PROCURVE 2910AL Configuration Guide

------- ------------ ------------ ------------ ------------
Multicast Listener Discovery (MLD) Snooping
Displaying MLD Status and Configuration
For example, the general form of the command:
ProCurve# show ipv6 mld statistics
MLD Service Statistics
Total vlans with MLD enabled : 2
Current count of multicast groups joined : 36
MLD Joined Groups Statistics
VLAN ID VLAN NAME filtered standard total
8 VLAN8 26 0 26
9 VLAN9 10 0 10
Figure 7-9. Example of MLD Statistics for All VLANs Configured
And the specific form of the command:
ProCurve# show ipv6 mld vlan 8 statistics
MLD Statistics
VLAN ID : 8
VLAN NAME : VLAN8
Number of Filtered Groups : 26
Number of Standard Groups : 0
Total Multicast Groups Joined : 26
Figure 7-10. Example of MLD Statistics for a Single VLAN
7-19

HP PROCURVE 2910AL Specifications

General

Model	HP ProCurve 2910al
Switching Capacity	128 Gbps
Throughput	95.2 Mpps
Management	Web, CLI, SNMP
Jumbo Frame Support	Yes
Manageable	Yes
Power	100-240 VAC
Power Supply	Internal
Operating Temperature	0°C to 45°C (32°F to 113°F)
Stacking	Yes
MAC Address Table Size	32000 entries
Routing Protocol	RIP, OSPF
Features	IPv6, VLAN, QoS, ACLs
Operating Humidity	15% to 95% non-condensing
Uplink Ports	4
Power over Ethernet	Yes (PoE+ models available)
