6-28
Configuring the Switch
Network Monitoring Port Features
Configuring the Switch
Network Monitoring Port Features
From the web browser interface and switch console you can designate a
port for monitoring traffic on one of the other switch ports. The monitoring is
accomplished by copying all traffic from the specified monitored port to the
designated monitoring port.
Note:
It is possible in networks with high traffic levels to copy more traffic to a
monitor port than the link can support. In this situation, some packets may
not be copied to the monitor port.
Configuring Port Monitoring from the Web Browser
Interface
Figure 6-12. Setting Up Port Monitoring from the Web Browser Interface
2. Click Here
1. Click Here
4. Select the port to use for the
Monitoring Port and the Port
to Monitor. Then click on
Apply Changes.
3. Select Monitor On
Sraswb.book : SIER_SW6.FM Page 28 Tuesday, June 30, 1998 12:20 PM
