Connectors, switches, and LEDs 94
Item Description
12 NIC 2 activity LED
13 Hard disk drive (HDD) bays
Figure 91 Front Panel Components / 8 2.5” SFF Hot-plug HDD Model
Item Description
1 Thumbscrews for rack mounting
2 Drive online/error LED
3 Drive activity LED
4 Serial number pull tab
5 Optical disc drive
6 Front panel USB 2.0 port 1/2
7 Front UID LED/switch
8 Hard drive activity LED
9 Power LED/switch
10 NIC 2 activity LED
11 NIC 1 activity LED
12 System health LED
13 Hard disk drive (HDD) bays
