3. Do one of the following:
a. Extend the server from the rack.
b. Remove the server from the rack.
4. Remove the access panel.
5. Remove the riser cage.
6. If a retaining screw is installed, remove the screw and then remove the expansion card.
To remove an expansion card from the secondary riser:
a. Remove the primary riser cage.
b. Lift the secondary rear wall.
c. Remove the expansion card.
To replace the component, reverse the removal procedure.
Removing and replacing the intrusion detection switch
Procedure
1. Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Do one of the following:
48 Removing and replacing the intrusion detection switch
