2 SFF NVMe backplane to primary riser
1 SFF rear backplane to system board SATA
Additional SFF cabling
For more information on the following cables and cabling configurations, see the HPE DL360 Gen10 Server
cabling matrix on the Hewlett Packard Enterprise website (http://www.hpe.com/info/CablingMatrixGen10):
• 8 SFF backplane to P408i-p controller
• 8 SFF backplane to system board SATA
• 8 SFF backplane power cable
• 2 SFF backplane to P408i-p controller
• 2 SFF backplane to system board SATA
• 2 SFF to 8 SFF power cable
• 1 SFF rear backplane to P816i-a controller
• SFF system power/USB cable
2 SFF NVMe backplane to primary riser 99
