Item Description
5 iLO Service Port
The operating system does not recognize this port as a
USB port.
6 USB 3.0 port
7 SAS/SATA drive bays
10 SFF NVMe/SAS Combo
Item Description
1 Serial label pull tab
2 Systems Insight Display (optional)
3 USB 3.0 port
4 SAS/SATA/NVMe drive bays
NVMe drives must be used in bays 9 and 10. SAS/SATA
drives are not supported in those bays.
Front panel LEDs and buttons
8SFF/10SFF
Front panel LEDs and buttons 81
