Illustrated parts catalog
Mechanical components
Hewlett Packard Enterprise continually improves and changes product parts. For complete and current
supported parts information, see the
Hewlett Packard Enterprise PartSurfer website.
Item Description
1 Access panel spare parts on page 7
2 PCIe riser cage spare part on page 7
3 PCIe riser blank spare parts on page 8
4 Miscellaneous blank spare parts on page 8*
5 Server ear and front bezel spare parts on page 8*
6 Rack mounting hardware spare parts on page 8*
7 Cable management arm spare parts on page 8*
*Not shown
Access panel spare parts
Customer self repair on page 110: mandatory
Description Spare part
number
Access panel 875536-001
PCIe riser cage spare part
Customer self repair on page 110: optional
Illustrated parts catalog 7
