To replace the component, reverse the removal procedure.
Removing and replacing the LFF power switch module
Procedure
1. Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Do one of the following:
a. Extend the server from the rack.
b. Remove the server from the rack.
4. Remove the access panel.
5. Disconnect the cable from the system board.
6. Remove the power module.
64 Removing and replacing the LFF power switch module
