14 HP ProLiant DL380 Generation 3 Server User Guide
Item Description Connector Color
1 Hot-plug PCI-X expansion slot 3
(bus 6) 64-bit/100-MHz 3.3V
N/A
2 Hot-plug PCI-X expansion slot 2
(bus 6) 64-bit/100-MHz 3.3V
N/A
3 Non-hot-plug PCI-X expansion slot 1
(bus 3) 64-bit/133-MHz 3.3V
N/A
4 Serial connector Teal
5 iLO connector N/A
6 Mouse connector Green
7 Power cord connector N/A
8 Keyboard connector Purple
9 NIC 1 connector N/A
10 NIC 2 connector N/A
11 USB connectors Black
12 Video connector Blue
13 VHDCI SCSI connector (port 1) N/A
