HP ProLiant DL380 - Installing Redundant Hot-Plug Fans

82 HP ProLiant DL380 Generation 3 Server User Guide
Item Description Zone Configuration
1 Fan 1 Processor Redundant
2 Fan 2 Processor Primary
3 Fan 3 I/O Redundant
4 Fan 4 I/O and processor Primary (shared)
5 Fan 5 Processor Primary
6 Fan 6 Processor Primary
7 Fan 7 Power supply and
processor
Primary (shared)
8 Fan 8 Power supply Redundant
Installing Redundant Hot-Plug Fans
1. Extend the server from the rack, if applicable ("Extending the Server from
the Rack" on page 38).
2. Remove the access panel ("Removing the Access Panel" on page 40).
