Hardware Options Installation 93
3. Open the PCI riser cage door.
CAUTION: To prevent improper cooling and thermal damage,
do not operate the server unless all PCI slots have either an expansion
slot cover or an expansion board installed.
4. Remove the expansion slot cover.
To replace the component, reverse the removal procedure.
