To replace the component, reverse the removal procedure.
Removing and replacing the air baffle
The air baffle must be installed in 1- and 2-processor configurations.
CAUTION:
For proper cooling do not operate the server without the access panel, baffles, expansion slot covers, or
blanks installed. If the server supports hot-plug components, minimize the amount of time the access
panel is open.
To remove the component:
Procedure
1. Power down the server (Power down the server on page 33).
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Do one of the following:
• Extend the server from the rack (Extend the server from the rack on page 33).
• Remove the server from the rack (Removing the server from the rack on page 34).
4. Remove the access panel (Removing the access panel on page 35).
5. Remove the air baffle.
Removing and replacing the air baffle 39
