Removal and replacement procedures 64
5.
Extend the processor memory drawer approximately 2.54-5.1 cm (1-2 inches).
6. Remove the SPI board (on page 31).
7. Loosen the thumbscrew, and then remove the FlexibleLOM from the server.
To replace the component, reverse the removal procedure.
Battery
If the server no longer automatically displays the correct date and time, you may need to replace the battery
that provides power to the real-time clock. Under normal use, battery life is 5 to 10 years.
