HP R/T3000 G4 ERM User Manual

Page 22
792519-001 Edition 1
ENGLISH
3. Installation
Mounting ERM on the rails
Follow steps 1 through 4 for mounting the ERM on the rails.
M3 screws
M3 screws
M3 screws
M6 screws
M6 screws
M6 screws
M6 screws
M6 screws
M6 screws
4
4
3
3
2
2
1
1
3.8 ERM and UPS installation
There are two ERM models. They can be installed with UPSs in both rack and tower installations. Up to four ERMs
can be installed with each UPS.
HP R/T3000 G4 ERM
HP R/T2200 G4 ERM

HP R/T3000 G4 ERM Specifications

General

Output Power Capacity	3000VA / 2700W
Topology	Double Conversion Online
Input Connection	IEC 320 C20
Rack Height	2U
Nominal Output Voltage	230V
Nominal Input Voltage	230V
Input Voltage	160 - 280V
Efficiency	Up to 95%
Operating Temperature	0 - 40°C
Form Factor	Rackmount/Tower
Output Connections	8 x IEC 320 C13, 2 x IEC 320 C19
Output Voltage	230V
Frequency	50/60 Hz
Battery Type	Sealed Lead-Acid (SLA)
Battery Recharge Time	3 hours
Communication Ports	USB, RS232
Warranty	3 years
