HP R/T3000 G4 ERM User Manual

Page 26
792519-001 Edition 1
ENGLISH
5. Maintenance
5.1 Troubleshooting
Operation status Possible cause
Action
Batteries disconnected
The UPS does not recognize
the internal batteries
If the condition persists, contact your
service representative
The batteries are disconnected
Verify that all batteries are properly
connected. If the condition persists,
contact your service representative.
Overload Power requirements exceeds the
UPS capacity (greater than 105 %
of nominal)
Remove some of the equipment
from the UPS. The UPS continues to
operate, but may shutdown if
the load increases. The alarm resets
when the condition becomes
inactive.
End of battery life
The end of the battery life is
reached.
Contact your service representative
for battery replacement.
Event An UPS event occurs
Example:
The RPO contact has been activated
to shutdown the UPS and now
prevents restart.
For this event, set the contact back
to its normal position and press the
button to restart.
UPS fault
The UPS has an internal fault The UPS does not protect the
equipment.
Note: Record the alarm message
and the UPS Serial Number, then
contact your service representa-
tive.
5.2 Updating the UPS rmware
To update the UPS rmware, see the HP website (http://www.hp.com/go/rackandpower).

HP R/T3000 G4 ERM Specifications

General

Output Power Capacity	3000VA / 2700W
Topology	Double Conversion Online
Input Connection	IEC 320 C20
Rack Height	2U
Nominal Output Voltage	230V
Nominal Input Voltage	230V
Input Voltage	160 - 280V
Efficiency	Up to 95%
Operating Temperature	0 - 40°C
Form Factor	Rackmount/Tower
Output Connections	8 x IEC 320 C13, 2 x IEC 320 C19
Output Voltage	230V
Frequency	50/60 Hz
Battery Type	Sealed Lead-Acid (SLA)
Battery Recharge Time	3 hours
Communication Ports	USB, RS232
Warranty	3 years
