Left side
Component Description
(1) Audio-out (headphone)/Audio-in (microphone)
combo jack
Connects optional powered stereo speaker assembly,
headphones, earbuds, a headset, or a television audio cable. Also
connects an optional headset microphone. This jack does not
support optional standalone microphones.
WARNING! To reduce the risk of personal injury, adjust
the volume before putting on headphones, earbuds, or a headset.
For additional safety information, refer to the Regulatory, Safety,
and Environmental Notices.
To access this guide:
▲ Select the Start button, select HP Help and Support, and
then select HP Documentation.
NOTE: When a device is connected to the jack, the computer
speaker assembly are disabled.
(2) USB Type-C power connector and port with HP
Sleep and Charge
Connects an AC adapter that has a USB Type-C connector,
supplying power to the computer and, if needed, charging
the computer battery.
– and –
Even when the computer is o, charges most products such as a
cell phone, camera, activity tracker, or smartwatch, and provides
data transfer.
– and –
Connects a display device that has a USB Type-C connector,
providing DisplayPort output.
NOTE: Cables and/or adapters (purchased separately) may
be required.
(3) AC adapter and battery light ● White: The AC adapter is connected and the battery is
fully charged.
● Blinking white: The AC adapter is disconnected and
the battery has reached a low battery level.
● Amber: The AC adapter is connected and the battery
is charging.
● O: The battery is not charging or the computer is in
the Sleep state, a power-saving state. The computer shuts
o power to the display and other unneeded components.
Left side 5
