Speaker assembly
Description Spare part number
Speaker assembly (includes left and right speaker assembly and cables and WLAN antenna cables
and transceivers)
L38700-001
Before removing the speaker assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
4. Remove the display panel (see Display panel on page 25).
5. Remove the webcam (see Webcam on page 36).
6. Remove the leather cover (see Leather cover on page 41).
Remove the speaker assembly:
1. Disconnect the speaker cables (1) from the system board.
2. Remove the Phillips M2.0×2.3 broad head screw (2) that secures WLAN support bracket to
the system board.
3. Remove the WLAN module support bracket (3).
NOTE: The WLAN support bracket is available using spare part number L38683-001.
46 Chapter 5 Removal and replacement procedures
