Keyboard
NOTE: The keyboard spare part kit includes the backlight cable and the keyboard cable.
For use in country: Spare part number For use in country: Spare part number
For use in Belgium L38709-A41 For use in the Netherlands L38709-B31
For use in Canada L38709-DB1 For use in Portugal L38709-131
For use in the Czech Republic and Slovenia L38709-FL1 For use in Russia L38709-251
For use in Denmark, Finland, and Norway L38709-DH1 For use in Saudi Arabia L38709-171
For use in France L38709-051 For use in South Korea L38709-AD1
For use in Germany L38709-041 For use in Spain L38709-071
For use in Greece L38709-151 For use in Switzerland L38709-BG1
For use in Hungary L38709-211 For use in Taiwan L38709-AB1
For use in Israel L38709-BB1 For use in Thailand L38709-281
For use in Italy L38709-061 For use in Turkey L38709-141
For use in Japan L38709-291 For use in the United Kingdom L38709-031
For use in Latin America L38709-161 For use in the United States L38709-001
Before removing the keyboard, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
4. Remove the display panel (see Display panel on page 25), and then remove the following components:
a. Webcam (see Webcam on page 36)
b. Leather cover (see Leather cover on page 41)
c. Speaker assembly (see Speaker assembly on page 46)
Remove the keyboard:
1. Disconnect the display panel cable (1) from the system board.
2. Disconnect the transfer board cable (2) from the system board.
3. Remove the four Phillips M2.5×3.4 broad head screws (3) that secure the display hinges to the keyboard.
Component replacement procedures 49
