Display
Component Description
(1) WWAN antennas* Send and receive wireless signals to communicate with wireless wide
area networks (WWANs).
(2) Internal microphones Record sound.
(3) Camera light(s) On: One or more cameras are in use.
(4) Camera Allows the computer to video chat, record video, and record still
images. Some cameras also allow a facial recognition logon to
Windows, instead of a password logon.
NOTE: Camera functions vary depending on the camera hardware
and software installed on the computer.
(5) Pen loop The leather pen loop is included in the product box. Follow
the instructions on the pen loop label to install the pen loop.
NOTE: Attach the loop to the plastic, not the leather cover.
For more information about the pen, see the documentation provided
with the pen.
(6) WLAN antennas* Send and receive wireless signals to communicate with wireless local
area networks (WLANs).
*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately around
the antennas free from obstructions.
For wireless regulatory notices, see the section of the Regulatory, Safety, and Environmental Notices that applies to the country or region.
To access this guide:
6 Chapter 2 External component identication
