Display panel

Description Spare part number

13.3-in, UHD (3840×2160), BrightView, WLED, UWVA, 400 nits, eDP+PSR, wedge TouchScreen display

panel with narrow bezel

L38698-001

13.3-in, FHD (1920×1080), BrightView, WLED, UWVA, 400 nits, eDP 1.4+PSR2, ultraslim TouchScreen

display panel with narrow bezel

L38696-001

13.3-in, FHD (1920×1080), BrightView, WLED, UWVA, 300 nits, eDP+PSR, ultraslim TouchScreen display

panel with narrow bezel

L38697-001

Before disassembling the computer, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and then

unplugging the AC adapter from the computer.

Remove the display panel:

NOTE: When using the heating gun in the following steps to dissolve the adhesive that secures the display

assembly, the heating gun temperature should be set to 60°C and the heating duration per edge should be

approximately 90 seconds.

1. Use a heating gun to apply heat to the bottom (1), left (2) and right, and top edges (3) of the display panel

to dissolve the adhesive that secures the display assembly.

2. Attach suction cups to the front left corners of the display panel and the display back cover.

Component replacement procedures 25
