3. Remove the solid-state drive shield (3).
NOTE: The solid-state drive shield is available using spare part number L38682-001.
4. Remove the solid-state drive by pulling it away from the connector.
NOTE: Solid-state drives are designed with notches to prevent incorrect insertion.
Reverse this procedure to install the solid-state drive.
Component replacement procedures 59
