Kickstand
Description Spare part number
Kickstand 922577-001
Before removing the kickstand, follow these steps:
1. Shut down the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the tablet.
3. Disconnect the power from the tablet by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the tablet.
4. Remove the display panel assembly (see Display panel assembly on page 20).
5. Remove the bottom bezel (see Bottom bezel on page 24).
6. Remove the battery (see Battery on page 25).
Remove the kickstand:
1. Remove the three Phillips PM2.0×3.8 screws (1) that secure the left bezel to the back cover.
2. Remove the left bezel (2).
The left bezel is available using spare part number 924165-001.
3. Remove the PM2.0×2.8 screw (1) that secures the right bezel to the back cover.
4. Remove the two Phillips PM2.0×3.8 screws (2) that secure the right bezel to the back cover.
