12. Remove the kickstand (4).
Reverse this procedure to install the kickstand.
Volume button board
Description Spare part number
Volume button board (includes cable) 924170-001
Before removing the volume button board, follow these steps:
1. Shut down the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the tablet.
3. Disconnect the power from the tablet by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the tablet.
4. Remove the display panel assembly (see Display panel assembly on page 20).
5. Remove the bottom bezel (see Bottom bezel on page 24).
6. Remove the battery (see Battery on page 25).
7. Remove the right bezel (see Kickstand on page 32).
Remove the volume button board:
Component replacement procedures 35

HP Spectre x2 Specifications

General

Display Size	12.3 inches
Operating System	Windows 10
Battery Life	Up to 8 hours
Processor	7th Gen Intel Core m3/i5/i7
RAM	4GB/8GB
Storage	128GB/256GB/512GB SSD
Wireless	802.11ac Wi-Fi, Bluetooth 4.2
Ports	microSD card reader
Audio	Bang & Olufsen with dual speakers
Webcam	5MP front-facing
Dimensions	11.57 x 8.15 x 0.52 inches
Resolution	3000 x 2000 pixels
