2. Detach the right microphone (2) from the back cover. (The right microphone is attached to
the back cover with double-sided adhesive.)
3. Remove the right microphone.
Reverse this procedure to install the microphones.
Webcams
Description Spare part number
Infrared camera (includes cable) 924841-001
Front-facing webcam (includes cable) 924842-001
Rear-facing webcam (includes cable) 924843-001
Before removing the webcams, follow these steps:
1. Shut down the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the tablet.
3. Disconnect the power from the tablet by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the tablet.
4. Remove the display panel assembly (see Display panel assembly on page 20).
5. Remove the bottom bezel (see Bottom bezel on page 24).
6. Remove the battery (see Battery on page 25).
Remove the infrared camera:
40 Chapter 5 Removal and replacement procedures
