MicroSD memory card reader board
Description Spare part number
MicroSD memory card reader board (includes cable and double-sided adhesive) 924835-001
MicroSD memory card reader bezel 924175-001
Before removing the microSD memory card reader board, follow these steps:
1. Shut down the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the tablet.
3. Disconnect the power from the tablet by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the tablet.
4. Remove the display panel assembly (see Display panel assembly on page 20), and then remove
the following components:
a. Bottom bezel (see Bottom bezel on page 24)
b. Battery (see Battery on page 25)
c. Fan (see Fan on page 31)
d. Microphones (see Microphones on page 38)
e. Webcams (see Webcams on page 40)
f. Heat sink (see Heat sink on page 44)
g. System board (see System board on page 46)
Remove the microSD memory card reader board:
1. Release the ZIF connector (1) to which microSD memory card reader board cable is connected, and then
disconnect the microSD memory card reader board cable from the system board.
Component replacement procedures 49
